EASYHEAT WarmTiles Floor Warming System

Ceramic tile, slate and marble floors are attractive and durable alternatives to wood, carpet or vinyl floors. Unfortunately these floors can be cold, even at room temperature. Warm Tiles® electric floor warming systems by EASYHEAT make cold floors pleasantly warm. The Warm Tiles electric floor warming system has been designed to gently warm flooring materials such as marble, ceramic and porcelain tile, laminate, slate, granite and poured or dimensional stone. Suitable for new construction or remodeling, the Warm Tiles system radiates gentle warmth through a network of low profile cables. UL Listed and CSA Certified, it is placed in the mortar just below the tiles, never compromising tile installation.  Although installing a Warm Tiles system is an easy task, we recommend using a knowledgeable installer.  Warm Tiles has been assigned a Light Commercial Floor Service Rating to the ASTM C627 Standard for Evaluating Ceramic Floor Tile Installation Systems (the Robinson floor test).   Installation involves locating the outlet box in the wall directly above area to be warmed and bringing appropriate power feed to the box. Determining the correct placement and spacing of cable attachment strapping, and attaching the strapping to the floor. Weaving the WarmTiles® cable to cover the area, snapping it into the strapping notches to maintain proper spacing. Installing flooring over the WarmTiles® cabling.  Installing the thermostat, including floor sensor previously installed with WarmTiles® cable, and energizing the circuit.

Warm Tiles fits in any room: bathrooms, kitchens, nurseries, living rooms-wherever you want tile floors. Operating on ordinary current, Warm Tiles comfort costs less than one cent per square foot per day when cables are installed together with the specially designed Warm Tiles thermostat. EASYHEAT offers all materials needed for a complete Warm Tiles electric floor warming system. UL Listed CSA Certified

FTS Thermostat:

Preprogrammed for easy set up Manual operation or 7-day/5-2 programming options Built-in ground fault protection Optional decorator door Installation tools included UL Listed FTS thermostats fit standard electrical boxes.

Get the best results from your electric floor warming system with Easy Heat’s Warm Tiles® FTS thermostats.  Attractive and suitable for any décor, they provide comfort, control and years of trouble free service.  Listed by Underwriters Laboratories Inc. to US and Canadian safety standards, these specially engineered controls are available in 120 VAC (FTS-1) or 240 VAC (FTS-2), designed with a Warm Tiles system in mind.  Embedded in the mortar just below your tiles, the floor sensor monitors actual floor temperature for accurate comfort control.  Each model features comfort-level programming options as well as a simple OFF-position selector switch. While the thermostat can operate in a traditional fashion, you may choose the pre-programmed set-back mode to reduce energy usage and costs by as much as 50%. Built-in ground fault protection helps confirm the safe operation of your floor warming system.  All Warm Tiles thermostat kits come complete with the thermostat and its sensor, instructions and hardware (Electrical Connection Box, Metal Guard Plates, Pull-Cord String and Warning Labels). Decorative recessed wall thermostat , digital, fully programmable, c/w  ground fault protection (7 milliamp protection), includes thermistor sensor, 120 or 240 volt, rated for 16 amps (requires customer supplied deep single gang electrical box).

Also included is a choice of attractive doors: with display window or without.

---

ET Thermostat: (Non-Programmable version of the FTS thermostat)

Decorative recessed wall thermostat , digital, Non-programmable, c/w ground fault protection (7 milliamp protection), includes thermistor sensor, 120 or 240 volt, rated for 16 amps (requires customer supplied deep single gang electrical box)

DT-1 Detecto Cable Fault Indicator

Senses if the cable is damaged during installation onto the subfloor BEFORE tile is installed.
Avoid mistakes that require pulling up tile.

Calculate total square footage of the area to be warmed. Do not include areas under vanities, cabinets and floor standing appliances, plumbing fixtures or inaccessible areas.

Each cable set covers a range of areas by adjusting spacing in LOW TRAFFIC areas of the room and/or by placing cable up to 6" away from walls.

Installation Instructions WarmTiles Installation Instructions in .pdf format WarmTiles FTS Thermostat Installation Instructions in .pdf format WarmTiles ET Thermostat Installation Instructions in .pdf format

You must have the free Adobe Acrobat Reader plug-in.

Match your true floor area (Walkable) with the Product Selector below.

Use the Warm Tiles Product Selector Charts below to calculate which Warm Tiles cable to buy.  You may have a typical installation, such as over a wood sub-floor, so follow the 3" column down to the area you have.  For special floor area considerations (floor areas of greater heat loss) - concrete slabs, basements, sunrooms, solariums, areas above unheated spaces such as garages, crawlspaces or basements - follow the 3"/1.5" column to the area you have.  Even if you do not have a floor area of greater heat loss, you can choose 3"/1.5" Spacing if you think that you will prefer a potentially warmer floor than normal. (You can always turn down the thermostat.)  Then, depending on your system size, choose one or more thermostats.

Secure Online Ordering Delivery time: typically ships in 1 working day or less plus allow additional time for your selected UPS or FedEx shipping method.  Your shipping cost will be displayed in your shopping cart.
Item ID	Catalog#	Kit Code	Coverage Area to be Warmed in Ft2 (less cabinets, fixtures & low traffic areas.)		Watts	Length (Ft.)	Amps	Price	Click "Select" below to see our actual real-time quantity in stock
			Standard Spacing (3” spacing)	Alternating Spacing (3”-1½”-3”-1½”-etc.)
120 Volt Kits:
EASY10295	DFT1011	Blue Kit	9-13	7-9	132	42	1.1	$70.24
EASY10296	DFT1016	Red Kit	14 - 18	10-13	193	62	1.6	$81.23
EASY10297	DFT1022	Green Kit	19 - 26	14 - 19	260	86	2.2	$103.60
EASY10298	DFT1030	Yellow Kit	27 - 34	20 - 26	363	121	3	$125.58
EASY10299	DFT1039	Purple Kit	35 - 42	27 - 33	480	155	4	$161.39
EASY10300	DFT1048	Orange Kit	43 - 54	34 – 39	616	190	5	$190.13
EASY10294	DFT1059	Brown Kit	55 - 65	40 - 48	766	235	6.4	$202.24
EASY10449	DFT1069	Beige Kit	66-72	49-54	895	275	7.5	$237.27
EASY10450	DFT1079	White Kit	73-82	55-62	1022	313	8.5	$250.46
EASY10451	DFT1088	Pink Kit	83-92	63-69	1055	350	8.8	$269.77
EASY10452	DFT1098	Silver Kit	93-102	70-76	1154	390	9.6	$289.56
EASY10453	DFT1108	Black Kit	103-113	77-85	1288	430	10.7	$305.45
120 Volt Thermostats: (can also be added to your shopping cart after selecting a kit above.)
EASY10095	FTS-1	Fully Programmable Digital Wall Thermostat, 16 amps, 120 Volts						$113.16
EASY10290	ET-1	Non-Programmable Wall Thermostat, 16 amps, 120 Volts						$72.34
EASY01300	RK-1	120 Volt Thermostat Relay Kit - Switches 2 separate multiple 120 VAC floor warming systems, each with a total 24 Amp maximum load						$32.14
240 Volt Kits:
EASY10301	DFT2021	A Kit	18 - 25	13 - 19	264	84	1.1	$103.60
EASY10302	DFT2031	B Kit	26 - 35	20 - 27	386	124	1.6	$135.11
EASY10303	DFT2053	C Kit	48 - 55	35 - 44	631	210	2.2	$193.64
EASY10304	DFT2065	D Kit	60 - 70	45 - 54	783	258	3.3	$232.36
EASY10305	DFT2078	E Kit	71 - 83	55 - 63	963	310	4.0	$248.32
EASY10306	DFT2095	F Kit	90 - 100	64 - 75	1232	380	5.1	$284.79
EASY10307	DFT2118	G Kit	110 - 130	84 - 94	1522	473	6.3	$321.34
EASY10308	DFT2137	H Kit	131 - 145	95 - 108	1790	549	7.5	$354.37
EASY10309	DFT2157	I Kit	146 - 165	109 - 125	2027	626	8.4	$379.92
EASY10310	DFT2175	J Kit	166 - 184	126 - 138	2109	700	8.8	$398.26
EASY10311	DFT2195	K Kit	185 - 204	139 - 153	2307	780	9.6	$415.74
EASY10312	DFT2215	L Kit	205 - 225	154 - 169	2576	860	10.7	$432.49
240 Volt Thermostats: (can also be added to your shopping cart after selecting a kit above.)
EASY10094	FTS-2	Fully Programmable Digital Wall Thermostat, 16 amps, 240 Volts						$113.16
EASY10291	ET-2	Non-Programmable Wall Thermostat, 16 amps, 240 Volts						$72.34
EASY01299	RK-2	240 Volt Thermostat Relay Kit - Switches multiple 240 VAC floor warming systems with a total 24 Amp maximum load						$33.99
Optional Accessories:
EASY10584	DT-1	Detecto Cable Fault Indicator						$16.69
EASY10317	DFTRK	WarmTiles Cable Repair Kit (Can be used with the new DFT system or the discontinued FT system.)						$19.84
EASY10221	10739-001	Replacement or Back-up Thermistor Sensor (Installing a second sensor as a back-up in case the one included with the thermostat fails is recommended.)						$16.22
EASY10254	DFTCK	Metal Strap Kit: 1 - 25' roll						$12.23
EASY10322	CKT	Concrete Kit Tape (25 Feet)						$22.26

EasyHeat and WarmTiles are registered trademarks of EasyHeat, Inc.
