Aube Technologies TH106, Line Voltage Thermostat, SPST 120V or 240V


We are an authorized distributor for
Aube Technologies


Link to other thermostats


Aside from providing unparalleled comfort, the TH106 is equipped with flexible programming to accommodate all types of schedules, a large and legible LCD screen as well as clearly identified buttons.

APPLICATIONS: Baseboards
Convectors
Radiant ceilings
LOAD: 4000 watts @ 240 volts
2000 watts @ 120 volts
16,7 A resistive load
250 watts min. (1A)
TEMPERATURE VARIATION: 0,15 °C ( ± 0,27 °F)
REGULATION: Proportional controller, 20 second cycles*
OPERATING MODES: Manual
Automatic with temporary bypass
PROGRAMMING: 4 settings / day
Each day can have different setbacks
Early start function***
Temperature memory****
PROTECTION: Protected memory
No battery required
CONNECTION: Single pole, 2 wires
SIZE: 38 x 127 x 125 mm
1,5 x 5 x 4,9 inches
* :
This thermostat is equipped with a micro processor that analyses the system's past performances in order to optimize future commands. At the beginning of each cycle, the system sends a command that defines the portion of time the unit is heating during the next cycle.
*** :
Function that calculates the optimum time to start the heating system to achieve the desired temperature setting at the programmed time.
**** :
The user can enter a daytime, night-time and vacation time temperature.


  Aube Instruction Manual

You must have the free Adobe Acrobat Reader plug-in.
  • Can be used with Fan-Forced Wall or Unit heaters:
    Heating cycles: 15 minutes
    Accuracy: ± 0.5ºC / 0.9ºF

Secure Online Ordering
*Delivery time: typically ships in 1 working day or less plus the time of your selected UPS shipping method.  Your shipping cost will be displayed in your shopping cart.

Item ID Catalog # Description Price Click "Select" below to see the actual quantity in stock
AUBE10003 TH106 16.7A 120/240V S.P.S.T., Programmable Line Voltage Digital Thermostat $63.67 Select

*This delivery time is for normal conditions and is subject to Aube factory availability.
