Qmark^® Type QTS Toe Space Fan-Forced Heater

Other Kickspace (Toe Space) Heaters

We are an authorized distributor for Qmark^®, a division of Marley Engineered Products.

Where all the wall space is used up by appliances and cabinets in your kitchen, basement or den, a toe-space heater will fit where no other heater will. It can be recessed into toe space areas under kitchen or utility room cabinets or into the soffit area above them. It can also be recessed into the risers of a stairway or under the vanity in the bathroom. It is convenient for checkout counters, ticket or tollbooths and many other places where no other heater seems to fit.

FEATURES

Multiple Wattage - Quick disconnects on wiring leads permit convenient means of changing the output from 1500 watts to 750 watts.

Small Size - Back box is 14 1/8" wide x 8 7/8" deep x 3 1/2" high (will fit in the most narrow of applications.) Front grille is 15 3/8" wide x 3 5/8" high

Over-temperature Protection - Each unit comes equipped with an automatic over-temperature protector that guards against overheating. Also standard is a pilot light that indicates the protector has operated. A thermal fuse provides a second level of over-temperature protection.

Uniform Heating Of All Discharge Air - Heavy gauge steel fins are brazed to low watt density steel sheathed tubular heating elements in a uniform grid pattern. The grid covers the entire discharge area, resulting in uniform heating of all discharge air, lower operating temperature and prolonged element life.

Quiet Operation - The tangential blower and the impedance protected, permanently lubricated motor provide trouble-free, quiet operation.

Three Piece Construction - A separate back box, fan deck and front cover make installation simple and quick. The slide in fan deck locks into place without the use of fasteners, cutting down on installation time.

Thermostat Options - The QTS1100 and QTS1104 Series units can be operated by either a built-in or remote wall mounted, double pole line voltage thermostat (M602W or WR-66). Model QTS1500T and QTS1504T are provided with factory installed thermostats and do not require a wall mounted thermostat.

Four Models - Two models available for replacement installation where a wall thermostat was used and only two power wires were run into the old unit. These units are available in 120 volt or 240/208 volt applications. Two other models with factory installed thermostats are available where higher wattage is required.

MOUNTING LIMITATIONS - Do not install heater behind towel rack, behind door, in floor, in closet, in ceiling, or where air flow may be obstructed. Thermostat range 45º to 85º F

U.L. listed

Qmark QTS1100 and QTS1104 Installation Instructions
Qmark QTS1500T and QTS 1504T Installation Instructions
Qmark QTS Bulletin Data Sheet
Wiring Instructions
You must have the free Adobe Acrobat Reader plug-in.

Secure Online Ordering
*Delivery time: typically ships in 1 working day or less plus allow additional time for your selected UPS or FedEx shipping method. Your shipping cost will be displayed in your shopping cart.

Item ID Catalog# Volts Watts Price Click "Select" below to see our actual real-time quantity in stock

QMARK685360065380 QTS1100 120 1125/563 $137.28

QMARK685360065397 QTS1104 240/208 1125/563/844/422 $137.28

QMARK685360065410 QTS1500T 120 1500/750 $150.12

QMARK685360065434 QTS1504T 240/208 1500/750/1125/564 $150.12

QMARK685360065335 QTSTSP Single pole thermostat kit for installation in QTS-1100 or QTS-1104 heater, 25A @ 120-240 VAC 45-85F range $24.14

QMARK685360065328 QTSAG Accessory Adapter Grille - 3-5/8"H x 23-3/8"W $21.72

Wall Mount Line Voltage Thermostat: (Optional)

The 1100 watt units can use either single pole or double pole wall thermostats. The higher wattage, 1500 watt units must use a double pole thermostat (3 conductors from the thermostat to the heater)

MEARS10014	M601W	White Mears Single Pole Thermostat, wall mount	$18.50
MEARS10005	M601	Ivory Mears Single Pole Thermostat, wall mount	$18.50
MEARS10009	M602W	White Mears Double Pole Thermostat, wall mount	$18.50
MEARS10008	M602	Ivory Mears Double Pole Thermostat, wall mount	$18.50

Qmark^® is a registered trademark of Marley Engineered Products.
