Qmark^® Type FDI Floor Drop In Heaters

We are an authorized distributor for Qmark®, a division of Marley Engineered Products.

• Quiet-for living rooms, dining rooms, even bedrooms.
• A "versatile, universal size," draft barrier heater for large window areas, sliding glass doors, entryways, hallways, open stair wells. Produces a flow pattern of warm air five feet wide (four feet above floor). Single compact size (14" length x 7 1/4" width x 6 5/8" depth).
• Both the FDl1500 and FDl1504 are adaptable from 1500W to 750W.
• Additionally, the FDl1504 may be operated at 208 volts for an output of 1125W or 563W
• Quick, simple installation. Mounts between floor joists in either direction (parallel or perpendicular to joists). Rough-in separate housing... then simply insert "plug-in" type heater element and fan assembly.
• Concrete accessory kit (housing pan cover and two stakes) aids installation of heater in concrete.
• Heavy-duty grille can take almost any type abuse!
• Thermostat accessory kit (optional) easily installed in heater (screwdriver adjusted thru grille). When heater is installed for overall room heating, use a wall thermostat.
• Automatic overheat thermal protector and thermal fuse standard.
• Heavy-gauge steel housing.
• Sandalwood baked enamel grille finish.
• 80 CFM
• Limitations: Do not install in bathroom or other areas where water may enter heater unit. Do not locate where air flow may be obstructed (under drapes, behind doors, etc.) Keep short sides at least 3' from side walls and long side 3" min. from side walls. Do not install in ceiling or wall.
• U.L. listed

Qmark FDI Installation Instructions Qmark FDI Data Sheet

You must have the free Adobe Acrobat Reader plug-in.

Secure Online Ordering *Delivery time: typically ships in 1 working day or less plus allow additional time for your selected UPS or FedEx shipping method.  Your shipping cost will be displayed in your shopping cart.
Item ID	Catalog#	Volts	Watts	Price	Click "Select" below to see our actual real-time quantity in stock
QMARK685360026268	FDI1500	120	1500/750	$170.88
QMARK685360026282	FDI1504	240/208	1500/750/1125/562	$170.88
QMARK685360026190	FDITSP	Accessory -  120 or 240 Volt - Integral Thermostat Kit		$24.14
Wall Mount Thermostats: (Optional)

MEARS10014	M601W	White Mears Single Pole Thermostat, wall mount	$18.50
MEARS10005	M601	Ivory Mears Single Pole Thermostat, wall mount	$18.50
MEARS10009	M602W	White Mears Double Pole Thermostat, wall mount	$18.50
MEARS10008	M602	Ivory Mears Double Pole Thermostat, wall mount	$18.50

Qmark^® is a registered trademark of Marley Engineered Products.
